Metallized BOPP Capacitor Film (sliver)

Metallized BOPP Capacitor Film (sliver film) have two items :
1. Zn/Al Metallized BOPP Capacitor Film (sliver film)
2. Al Metallized BOPP Capacitor Film (sliver film)
reinforced edge ( of Aluminum/Zinc film ) are : 1.5,2.0,2.5 MM
The standard thickness range including: 3,4,5,6,7,8,9,10,12 microns .
The standard tolerance thickness: +/-0.2 Um .
The standard width range including: 30,40,50,60,70,80,90,100,120,130 MM
The standard tolerance width: +/-5 MM.
The inner core : 3" (76MM)
The outer core: 150-350 MM .
Features:
1) single side corona treated for the Zn or Zn/Al metallized .

Ask questions now

Make an inquiry now

1 Asia Pacific -BOPP Film For Capacitor Type MPP-Compressed.pdf

2 Asia Pacific -BOPP Capacitor-Usage Film Clear & Metallized-Compressed.pdf

3 Asia Pacific -BOPP Capacitor Clear & Metallized Film (Tech Data)-Compressed.pdf

4 Asia Pacific -Technical Data Of BOPP RPP & RRPP Rough Film-Compressed.pdf

5 Asia Pacific -BOPP-Introduction Of Metalized PP Film-Compressed.pdf

6 Asia Pacific -Tech Data -BOPP & BOPET-Compressed.pdf

7 Asia Pacific -ISO14000 -BOPP & BOPET.pdf -compressed.pdf

8 Asia Pacific -ISO9001 -BOPP & BOPET -compressed.pdf

Ask questions now

Make an inquiry now

Metallized BOPP Capacitor Film (sliver)

 Metallized BOPP Capacitor Film (sliver film) have two items :
1. Zn/Al Metallized BOPP Capacitor Film (sliver film)
2. Al Metallized BOPP Capacitor Film (sliver film)
reinforced edge ( of Aluminum/Zinc film ) are : 1.5,2.0,2.5 MM
The standard thickness range including: 3,4,5,6,7,8,9,10,12 microns .
The standard tolerance thickness: +/-0.2 Um .
The standard width range including: 30,40,50,60,70,80,90,100,120,130 MM
The standard tolerance width: +/-5 MM.
The inner core : 3" (76MM)
The outer core: 150-350 MM .
Features:
1) single side corona treated for the Zn or Zn/Al metallized .
