Home / Products/ BOPP Printing & Laminating Film

< >

Plain BOPP Film (Bi-axially Oriented PolyPropylene) For Printing And Lamination

Product code:

Wholesale price:

Description

Plain BOPP Film (Bi-axially Oriented PolyPropylene) For Printing And Lamination

BOPP film is widely used for plain, lamination, matte and metalized films which are used for many different sorts selection of applications, such as carton box, flower, gift, food, confectionery, lamination, CD, DVD, VCD, cigarette, and box packaging, packing tape, etc according to its purpose such as printing, clothes, tape and laminating which are used for many different sorts of applications as the selection follow.
BOPP film is a packing film with a superior mechanical nature, transparent and moisture proof formed through the processing of draft Bi-axially Oriented Polypropylene (BOPP) vertically and horizontally.

Parameter	Value
Thickness	10UM, 12UM ,15UM,18UM for lamination , 20UM, 23UM ,25UM,28UM,30UM,35-52UM for printing , 23UM ,25UM,28UM for adhesive tape's basic material , 35UM,37UM,40UM,50UM for BOPP Bag's basic material,
Width	350MM-1600MM
Length	2000M ,3000M ,4000M ,7000M,8000M,9000M
Corona treated side	Single(one) side or double (two)sides
Heat sealable	Non-heatsealable
Application	Printing, lamination , Aluminium metallization and so forth
Color	Transparent ,clear
Inner core	76 mm(3') ,152mm(6')
Package method	Use carton with Bubble film around rolls and (wooden or plastic) pallets
Loading details	1.Use 20GP ,40GP ,40HQ . 2. Per 20GP . With pallets , can load 12-15 tons . If the width of the roll is less than 500MM (such as 350MM) ,can load 12 tons , otherwise ,width of the roll is more than 500MM (such as 900MM ) can load about 15 tons . Without pallets , per 20GP can load 16-18 tons , of course the width of the roll is the key for the quantity loading under the same case . 3. Per 40GP ,With pallets(usually use 40HQ ), can load 24-25 tons . If the width of the roll is less than 500MM (such as 350MM) ,can load 24 tons , otherwise ,width of the roll is more than 500MM (such as 900MM ) can load around 25 tons . Without pallets , per 40GP can load 26-27 tons , of course the width of the roll is the key for the quantity loading under the same case .

Featuring details :
Main Properties
High transparency and gloss
High tensile strength
High grease barrier
Excellent ink and coating adhesion
Low static electricity
Superior thickness uniformity
Smooth rolling and neat ends of film rolls
Specifications
Thickness:12～52 micron
Width:350～1600 mm
Customized dimensions and specifications are available upon request.

Tech Data ( Physical Properties) For Customer Reference :

BOPP PLAIN FILM
Standard : GB/T1003-96.

1、Machinability

Items

Prime

Eligible

Weak

Test method

Marking

Tensile strength in machine

GB13022-91

≥150

≥260

≥120

≥260

Elongation in machine

GB13022-91

≤180

≤65

≤180

≤65

Elasticity（Three days later）

Mpa

GB13022-91

≥1700

Thermal contraction %

GB/T1003-96

≤4

≤2

≤5

≤3

Haze %

GB2410-80

≤1.2

≤1.5

Transparency stability %

GB2410-80

≥85

Gloss %

GB8807-88

≥90

≥85

Wettability mN/m

GB/T14216-93

≥39

≥38

Fraction coefficient %

GB/10006-88

≤0.8

2、Dimension

Items

Prime

Eligible

Weak

Dimensional Stability

±3.0%

±4.5%

±7.0%

Averagabal DimensionalStability

±2.5%

±4.0%

Length Stability

＜30um ±300 M

≥30um ±150M

±800 M

±400M

The length of junction

＜20um ＞1000M

20~30um ＞800M

＞30um ＞500M

＞500M

Width Stability

≤±2mm

＞±2mm

3、Appearance

Items	Prime	Eligible	Weak	Test method	Marking
Damage of core	NO	NO	YES	By sight	O
Damage of edge	NO	A LITTLE	BADLY	By sight	B
Joint	One joint is allowed	2 joints	5 jionts	By sight	J
		allowed
Deflection	≤1mm	≤3mm	＞3mm	By ruler	P
Warp on eldge	NO	NO	Obviously	By sight	G
Dent	NO	NO	/	By sight	V
Color distinction	NO	Obviously	/	By sight	D
Bruise	NO	Obviously	Obviously	By sight	R
Contamination	NO	NO		By sight	W
Balloon	Diameter ＜0.5mm One or two, diameter＜0.5mm three	Yes	/	By sight	K
Material leakage	NO	Lightly	Badly	By sight	H
Dyne distinction	≥38	≥36			U
Damage	No	Lightly	Badly		X
Width	±1	±2			A
Length distinction	Do as clients	Light distinction	Badly	Bycomputer	C

4、Roll’s quality

Items	Prime	Eligible	Weak	Test method	Marking
Dent	Width below 1000mm≤50m Width above 1000mm≤100m	≤250m	/	By sight	F
Dent inside	No	No	＞300m	By sight	L
Longitudinal marking	No	No		By sight	T
Traversenal marking	No	No	/	By sight	M
Blotch	No	Lightly	/	By sight	Q
