BOPET Thermal Lamination Film
Application: Laminating film can be applied to various types of materials such as ID cards,cultural and historical
documents,credit cards,licenses,business certificates.
Main property: low heat shrinkage,good ink and metal adhesion
good dimensional stability,excellent processing ability
PET EVA Film Applications:
1) Books and magazines, pictures, promotional materials; non-drying
adhesive, paper bag, clothes lag, liquor, food, cosmetic, medicine
wrapping box
2) Blueprint document, outdoor advertisement, spray paintings, post,
digital print
3) Wedding photograph, photo album
4) The width is from 330mm to 1800mm
5) widely laminating on:
1>paper bag,
2>paper box.
3>all paper product
Thermal PET film(EVA film):
Pre-coated Film (38 micron):
Composition: PET-12micron, EVA-26micron Roll Film
Using purpose: book-cover, presswork, advertisement
Features: Compared to OPP, using PET to produce the pre-coated film has the following advantages:
(1), High- transparency and brightness
(2), Strong performance in resisting ultraviolet radiation and aging; Being able to bear fresh and preventing scrape.
(3), Relative low cost
| Specifications | ||
| Thickness | Width | Roll ID |
| 12-50 µm | 350-2200 mm | 76.2mm(3”), 152.4mm(6”) |
| Typical Value | ||||||
| Property | Unit | Typical Value | Test Method | |||
| Thickness | µm | 12 | 36 | 50 | DIN 53370 | |
| Tensile Strength | MD | MPa | 220 | 220 | 210 | DIN 53455-6-5 |
| TD | 250 | 250 | 250 | |||
| Elongation at Break | MD | % | 140 | 160 | 170 | DIN 53455-6-5 |
| TD | 100 | 100 | 100 | |||
| Heat Shrinkage | MD | % | 1.8 | 1.8 | 1.8 | ASTM D1204 |
| TD | 0.2 | 0.2 | 0.2 | 150°C,30min | ||
| Friction Coefficient | µs/µk | 0.45/0.45 | 0.45/0.40 | 0.40/0.35 | DIN 53375 | |
| Gloss(45o) | % | 135 | 135 | 135 | ASTM D 2457 | |
| Haze | % | 2.5 | 2.5 | 3 | ASTM D 1003 | |
| Surface Tension | Dyne/cm | 38 | 38 | 38 | ASTM D 2578 |
Applications:Laminate the surface of Books, catalogs, samples, posters, printed paper, Food, medicines, cosmetics, gifts, wine boxes and other packaging film ,Drawings, documents, ads, pictures, display boards, etc.
