BOPET INSULATING FILM (PET Switch film)

Name: BOPET INSULATING FILM (PET Switch film)
Brand: Asia Pacific Industry Group
SKU: 264

Product code:APIG-264

H.S. code:3920620000

Wholesale price:$3.25 /only

Category:BOPET Film (Polyester Film)

BOPET INSULATING FILM (PET Switch film)

Features:

Thickness : 75-95,100-150,180-250,250-380,400-500 microns.
Color: Clear,White,Pearlized,Black...

Width : 325-1500mm

Length: 50-1000M
Packing: Use pallets
Technology data:

CLEAR BOPET FILM TECHNOLOGY DATA

SPEC.	150UM BOPET CLEAR FILM	ITEM
PROPERTIES	UNITS	TYPICAL VALUES
THICKNESS	UM	150
TENSILE STRENGTH	MD	MPA	162.7
TD	MPA	193.8
ELONGATION	MD	%	168.2
TD	%	149.8
HEAT SHRINKAGE	MD	%	1.4
TD	%	0.52
HAZE	%	3.38
TRANSPARENCE	%	88.96
SURFACE TENSION	DYN/CM	56
FRICTION COEFFICIENT	µS/µD	0.413--
GLOSS INDEX	GS	143.2
AVERAGE THICKNESS	µM	149.7
AVERAGE THICKNESS TOLERANCE	％	1.5
MIN. THICKNESS TOLERANCE	％	-1.38
THICKNESS TOLERANCE	％	-0.8

T: 24℃ RH：50％ QUALITY INSPECTOR:

WHITE BOPET FILM TECHNOLOGY DATA

SPEC.	150UM BOPET WHITE FILM	ITEM
PROPERTIES	UNITS	TYPICAL VALUES
THICKNESS	UM	150
TENSILE STRENGTH	MD	MPA	178.2
TD	MPA	150.8
ELONGATION	MD	%	164.2
TD	%	119.8
HEAT SHRINKAGE	MD	%	0.81
TD	%	0.32
HAZE	%	91.08
TRANSPARENCE	%	19.96
SURFACE TENSION	DYN/CM	56
FRICTION COEFFICIENT	µS/µD	0.443
GLOSS INDEX	GS	58
AVERAGE THICKNESS	µM	149.7
AVERAGE THICKNESS TOLERANCE	％	2.1
MIN. THICKNESS TOLERANCE	％	-1.78
THICKNESS TOLERANCE	％	-0.8

T: 24℃ RH：50％ QUALITY INSPECTOR:
