BOPET CAPACITOR FILM
It is used for film-capacitor (and other electrical insulation material.) which features dielectric strength, dielectric constant and volume resistance, low dielectric loss, good mechanical performance and dimension stability.
Thickness :3-12 UM
Width : 500,620,670 MM
Net weight per roll about : 50KGS/roll
Inner plastic tube core : 3”,6” (76MM ,152MM )
By the way , we also manufacture the BOPET metalized (VM/--Zn /Al ) capacitor film.
Technological data for customer’s reference ,
Density | g/cm3 | 1.400+/-0.005 | ||
melting point | ℃ | ≥256 | ||
Thickness | UM | 3-12 | ||
Width of roll | MM | 500,620,670 | ||
Inner plastic tube core | MM | Um2 | Um2 | Um2 |
Net weight | kg | 40-110 | ||
Other size | Can negotiate | |||
Tensile strength | MD | MPA | ≥200 | Tensile rate 100mm/min@23℃,50％r.h. |
TD | MPA | ≥210 | ||
Elongation at break | MD | % | ≥70 | |
TD | % | ≥70 | ||
Resistance modulus | MD | N/mm2 | ≥3500 | |
TD | ≥3500 | |||
Thermal shrinkage | MD | % | ≤3 | 30min@150℃ |
TD | % | ≤2 | ||
Wetting tension | mN/m | ≥40 | 23℃ | |
Surface roughness | um | 0.06-0.15 | @23℃,50％r.h. | |
BDV X | v/um | ≥3000 | 50Hz or 1kHz @ 23℃ | |
Relative permittivity | 3.2+/-0.2 | 23℃ | ||
Volume resistivity | Ω/cm | ≥10 | 1kHz @ 23℃ 200V/um | |
Dielectric dissipation factor(tan delta) | ≤0.005 | 200V/um | ||
Film Uniformity in thickness | 3.0-3.9 | Um2 | ||
4.0-5.9 | Um2 | |||
6.0-9.9 | Um2 |
