BOPP 印刷复合膜

产品编码:

批发价格:

分享 facebook

查看详情

立即咨询

产品描述

BOPP 印刷复合膜

一、BOPP 平膜

较成熟, 标准化程度高, 目前占国内市场约70%, 主要分为印刷复合膜、胶粘带膜和制袋膜, 但仍有多种用户认可的差异化途径:

1 高透明( 雾度≤0.3) 、高光泽( 光泽度≥99%) , 应用于超透明胶粘带、与纸类制品复合等;

2 低静电( ≤1013) , 用于电子元件包装、适宜复合切片堆叠和自动化包装等;

3 耐磨花( ≥20S, 普通膜≤3S) , 用于直接制冷封袋或针织品包装等;

4 电晕值长效( 6 个月≥42mN/m) , 适宜产品出口, 用于高速印刷、复合、涂布等;

5 浅网印刷, 要求表面微观平整, 电晕值高;

6 高挺度, 质感好, 可减少薄膜厚度, 降低成本;

7 开口性好, 便于产品包装;

8 疵点少, 1000m2 中不允许有大于Φ1.0mm 疵点, Φ0.5- 1.0mm 的疵点≤2 个;

二、BOPP 热封膜

应用于印刷、复合制袋或盒体保护等方面。◆ 超低温起封或宽热封温度范围( 80-135℃) , 高爽滑( COF≤0.25) , 高电晕保持值( 6 个月≥42mN/m) , 适用于高速印刷复合包装或性能差异大的包装设备;

1 低静电, 用于粉剂包装;

2 高热封强度( 5- 12N/15mm) , 取代复合膜直接印刷制袋;

3 高挺度, 提高包装速度, 减少厚度;

4 吸管专用包装膜, 适宜的透明度、光泽度、摩擦系数和热封强度。

三、BOPP 消光膜

常用于书册、广告册、礼品袋、食品包装等, 外观有立体感。

1 外观无疵点, 适宜与深色纸类制品复合;

2 镀铝附着力强, 上色镀铝具有丝绸质感;

3 上UV 油墨或烫金加工性能好

4 高挺度, 可减少厚度, 易于复合加工。

四、BOPP 烟膜

可用于香烟、医药和化装品等盒体的外包装。

1 高挺度, 弹性模量:MD≥3000MPa,TD≥5000MPa;

2 高爽滑, COF≤0.2;

3 高透明, 雾度≤0.7%, 高光泽≥99%;

4 耐磨花

5 热封温度范围广

6 收缩烟膜印刷或涂布性能好。五、BOPP 拉线膜

用于盒体外包装膜的撕裂线。

1 保持高的后加工热收缩, MD≥5.5%;

2 易于印刷、镀铝和涂布加工;

六、BOPP 珠光膜

用于雪糕、糖果、香皂、洗衣粉、筷子等物品的包装以及环型标签。

1 单位面积重量均匀, 稳定, 密度≤0.7g/cm3

2 透光率≤48%, 白度≥88%

3 热封强度≥1.2N/15mm;

4 耐寒性好;

5 环型标签膜: 高挺度、低静电、高光泽、高白度、珠光色泽好、良好的印刷复合性能。

七、BOPP 合成纸

产品特点: 防水、耐撕, 优良的加工适应性, 适用于凸版、凹版、平版、网版等印刷和烫金、钻孔等天然纸的后加工过程, 由单一材质制成, 可回收使用, 密度低。

应用: 电脑喷绘底纸、复合原料包装袋、名片、网印海报、餐桌布、地图、商业平版印刷海报、礼品包装纸、防潮布、杂志、书刊用纸、花卉包装纸、面材保护纸、吊牌、标签( 特别是模内标签膜) 、礼品袋等。

1 良好的遮光度: 透光率≤32%;

2 高白度: ≥88%;

3 密度: 0.55- 0.80g/cm3

4 表印性能优越, 耐磨花;

5 尺寸稳定性好

6 良好的耐候性

八、BOPP 镀铝膜基材

经蒸镀后的薄膜具有金属般光泽的表面和良好的阻隔性( 气体、光线等) , 有特殊的装饰效果, 可用于许多食品( 如茶叶、饼干、干果等) 的包装。

1 镀铝附着力强

2 高光泽度≥96%

3 高刚性

4 可热封: 3- 7N/15mm, 高热封强度, 可取代CPP 镀铝复合膜

5 高阻隔性能, 透湿: ≤0.8g/m2.24h透氧: ≤3cc/m2.24h

九、BOPP 镭射膜( 激光模压膜)

非转移镭射膜模压或镀铝后模压与纸制品或薄膜复合或直接用于烟盒、药盒、化装品盒、食品盒或袋的包装等。可转移镭射膜, 产品模压镀铝涂胶后与卡纸复合剥离转移再表印加工用作防伪香烟盒或药盒等包装; 与热封薄膜复合后剥离转移, 用作防伪食品等包装。

1.尺寸稳定性好, 模压性能佳;

2.模压膜面外观清晰, 亮点或疵点少;

3 后加工适应性好;

4 产品模压后出现的全息光栅衍射强度均一、稳定;

5 转移膜: 品模压镀铝转移完全, 剥离速度快, 无反粘等异常现象, 产品模压镀铝较长时间仍能保持良好转移效果, 可印刷性好。十、BOPP 扭结膜

用于糖果扭结包装, 环保卫生方面取代PVC 材料, 价格方面优于BOPS、BOPET 扭结膜和玻璃纸。

1 挺度高、刚性强

, , , , , 2 高光泽

3 镀铝附着力强

4 扭结性能好, 回弹少。

十一、BOPP 防雾膜( 抗菌、透气)

用于新鲜水果、蔬菜、色拉、食用菌等包装, 冷藏时清晰看到内容物, 并防止食品变质腐烂。

1 防雾效果好( 冷热状态可防雾)

2 透气: ≥4000cc/m2.24h

3 热封性能好

4 柔软

十二、BOPP 离型膜

取代BOPET、CPP 等直接制作或背涂硅油用于医药、无声胶粘带和其它涂胶产品的保护。

1 高挺度

2 外观疵点少

3 热尺寸稳定性好

十三、BOPP 缠绕膜

用于钓鱼杆、高尔夫球杆、其它工业制品的保护。

1.拉伸强度高

2.尺寸稳定性好

3.外观疵点少

十四、BOPP 电容器薄膜

1 金属化电容器薄膜: 耐高温( ≥105℃) ,用于汽车电池、灯具等的用品的电容器。

2 薄型化

十五、其它差异化用途

1. 极低气味BOPP 薄膜: 减少对食品气味的污染或干扰;

2. 耐温、阻燃BOPP 薄膜: 电路板或元件干燥固化

3. 抗撕裂BOPP 薄膜: 取代复合膜

4. 低移转BOPP 薄膜: 减少内容物的污染, 适宜高

立即咨询

调查咨询
技术参数

1 Asia Pacific -Technology Data Of 10 15 18 23 Mic BOPP Clear & Metallized-Compressed.pdf

2 Asia Pacific - BOPP Plain Film-Compressed.pdf

3 Asia Pacific -Bag-Grade BOPP Film With Corona Treated-Compressed.pdf

4 Asia Pacific -Technical_BOPP Foil, Transparent,-Compressed.pdf

5 Asia Pacific -BOPP compressed.pdf

6 Asia Pacific - BOPP Clear Wrapping Foil Film Transparent-Compressed.pdf

立即咨询

调查咨询

详细信息

Plain BOPP Film (Bi-axially Oriented PolyPropylene) For Printing And Lamination

BOPP film is widely used for plain, lamination, matte and metalized films which are used for many different sorts selection of applications, such as carton box, flower, gift, food, confectionery, lamination, CD, DVD, VCD, cigarette, and box packaging, packing tape, etc according to its purpose such as printing, clothes, tape and laminating which are used for many different sorts of applications as the selection follow.
BOPP film is a packing film with a superior mechanical nature, transparent and moisture proof formed through the processing of draft Bi-axially Oriented Polypropylene (BOPP) vertically and horizontally.

Parameter	Value
Thickness	10UM, 12UM ,15UM,18UM for lamination , 20UM, 23UM ,25UM,28UM,30UM,35-52UM for printing , 23UM ,25UM,28UM for adhesive tape's basic material , 35UM,37UM,40UM,50UM for BOPP Bag's basic material,
Width	350MM-1600MM
Length	2000M ,3000M ,4000M ,7000M,8000M,9000M
Corona treated side	Single(one) side or double (two)sides
Heat sealable	Non-heatsealable
Application	Printing, lamination , Aluminium metallization and so forth
Color	Transparent ,clear
Inner core	76 mm(3') ,152mm(6')
Package method	Use carton with Bubble film around rolls and (wooden or plastic) pallets
Loading details	1.Use 20GP ,40GP ,40HQ . 2. Per 20GP . With pallets , can load 12-15 tons . If the width of the roll is less than 500MM (such as 350MM) ,can load 12 tons , otherwise ,width of the roll is more than 500MM (such as 900MM ) can load about 15 tons . Without pallets , per 20GP can load 16-18 tons , of course the width of the roll is the key for the quantity loading under the same case . 3. Per 40GP ,With pallets(usually use 40HQ ), can load 24-25 tons . If the width of the roll is less than 500MM (such as 350MM) ,can load 24 tons , otherwise ,width of the roll is more than 500MM (such as 900MM ) can load around 25 tons . Without pallets , per 40GP can load 26-27 tons , of course the width of the roll is the key for the quantity loading under the same case .

Featuring details :
Main Properties
High transparency and gloss
High tensile strength
High grease barrier
Excellent ink and coating adhesion
Low static electricity
Superior thickness uniformity
Smooth rolling and neat ends of film rolls
Specifications
Thickness:12～52 micron
Width:350～1600 mm
Customized dimensions and specifications are available upon request.

Tech Data ( Physical Properties) For Customer Reference :

BOPP PLAIN FILM
Standard : GB/T1003-96.

1、Machinability

Items

Prime

Eligible

Weak

Test method

Marking

Tensile strength in machine

GB13022-91

≥150

≥260

≥120

≥260

Elongation in machine

GB13022-91

≤180

≤65

≤180

≤65

Elasticity（Three days later）

Mpa

GB13022-91

≥1700

Thermal contraction %

GB/T1003-96

≤4

≤2

≤5

≤3

Haze %

GB2410-80

≤1.2

≤1.5

Transparency stability %

GB2410-80

≥85

Gloss %

GB8807-88

≥90

≥85

Wettability mN/m

GB/T14216-93

≥39

≥38

Fraction coefficient %

GB/10006-88

≤0.8

2、Dimension

Items

Prime

Eligible

Weak

Dimensional Stability

±3.0%

±4.5%

±7.0%

Averagabal DimensionalStability

±2.5%

±4.0%

Length Stability

＜30um ±300 M

≥30um ±150M

±800 M

±400M

The length of junction

＜20um ＞1000M

20~30um ＞800M

＞30um ＞500M

＞500M

Width Stability

≤±2mm

＞±2mm

3、Appearance

Items	Prime	Eligible	Weak	Test method	Marking
Damage of core	NO	NO	YES	By sight	O
Damage of edge	NO	A LITTLE	BADLY	By sight	B
Joint	One joint is allowed	2 joints	5 jionts	By sight	J
		allowed
Deflection	≤1mm	≤3mm	＞3mm	By ruler	P
Warp on eldge	NO	NO	Obviously	By sight	G
Dent	NO	NO	/	By sight	V
Color distinction	NO	Obviously	/	By sight	D
Bruise	NO	Obviously	Obviously	By sight	R
Contamination	NO	NO		By sight	W
Balloon	Diameter ＜0.5mm One or two, diameter＜0.5mm three	Yes	/	By sight	K
Material leakage	NO	Lightly	Badly	By sight	H
Dyne distinction	≥38	≥36			U
Damage	No	Lightly	Badly		X
Width	±1	±2			A
Length distinction	Do as clients	Light distinction	Badly	Bycomputer	C

4、Roll’s quality

Items	Prime	Eligible	Weak	Test method	Marking
Dent	Width below 1000mm≤50m Width above 1000mm≤100m	≤250m	/	By sight	F
Dent inside	No	No	＞300m	By sight	L
Longitudinal marking	No	No		By sight	T
Traversenal marking	No	No	/	By sight	M
Blotch	No	Lightly	/	By sight	Q
